JTAG-Booster for IDT 64145
1.6.
Initialization file JTAG145.INI
This file is used to set the CPU signals for input/output. In case of output signal
an additional parameter is used to set the default level to high or low. This file
can be used to adapt your own IDT RC64145 design to the JTAG-BOOSTER.
The Target-Entry is used to identify your design which is displayed with most
commands.
When the JTAG145 software is started it scans the current directory for an
existing initialization file named JTAG145.INI. If no entry is found the default
values are used. You may also specify the initialization file with the option
/INI= . If the specified file isn't found, the program aborts with an error message.
The CPU pins can also be used with the functions /BLINK (chapter 2.9), /PIN?
(chapter 2.10) and /SAMPLE (chapter 2.11) to test the signals on your design.
Example of JTAG145.INI:
// Description file for IDT RC64145
Target: Generic Target
// All chip select signals are set to output and inactive.
// All signals should be defined. Undefined signals are set to their defaults.
// Pin names are defined in upper case.
// The following pins are complete bidirectional pins.
// The direction of each pin can be set independent of the other pins.
// Each pin can be used as input.
CPU_AD31
CPU_AD30
CPU_AD29
CPU_AD28
CPU_AD27
CPU_AD26
CPU_AD25
CPU_AD24
CPU_AD23
CPU_AD22
CPU_AD21
CPU_AD20
CPU_AD19
CPU_AD18
14
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
Inp
// Address/Data to/from CPU
//
//
//
//
//
//
//
//
//
//
//
//
//
JTAG145a.doc
